24 AWG solid bare annealed copper conductors, non-plenum, Thermoplastic Polyolefin insulation, centre spline, rip cord, twisted pairs, see color

code chart (below), PVC jacket (blue or gray).

SUITABLE APPLICATIONS:

Suitable Applications

PHYSICAL CHARACTERISTICS:

CONDUCTOR:

Number of Pairs : 4

Total Number of Conductors : 8

AWG : 24

Stranding : Solid

Conductor Material : Bare Annealed Copper

INSULATION:

Insulation Material : Thermoplastic Polyolefin

Pair Color Code Chart :

Number Color Number Color

1 White/Blue Rings & Blue 3 White/Green Rings & Green

2 White/Orange Rings & Orange 4 White/Brown Rings & Brown

OUTER SHIELD : Outer Shield Material Unshielded

OUTER JACKET:

Outer Jacket Material : PVC

Outer Jacket Ripcord : Yes

NEC/(UL) Specification CM

CEC/C(UL) Specification CM

IEC Specification ISO 11801

TIA/EIA Specification 568-B.2-1 Category 6

Other Specification Category 6, UL verified to Category 6, ETL, ANSI/TIA/EIA-568B.2-1

OVERALL NOMINAL DIAMETER:

Overall Nominal Diameter 5.80 0.50mm
