specifications

basic

function

Number of control axes

2 axis (X,Z)

Number of linkage axes

Full linkage

Simulation spindle

2 routes

Spindle ratio

50%~120%

Minimum instruction unit

0.001 mm

Maximum instruction value

±99999999×Minimum

instruction unit

Rapid feed rate

12000 mm / min

Rapid feed rate

F0, 25%, 50%,

100%

feed rate

12000 mm / min

Rate feed rate

10%～150%

Electronic gear ratio

1～65535: 1～65535

Automatic acceleration and deceleration

yes

location

G00 (linear

interpolation positioning)

interpolation

Straight line

(G01), arc (G02 / G03 / G05)

Return to reference point

Automatic return

to reference point (G28)

LCD

3.5-inch TFT LCD

with resolution of 480x320

MDI software key

Five

Single step feed

x1，x10，x100

communication interface

U disk interface

External handwheel interface

yes

I / O interface

24 / 24

(expandable to 96 / 96)

Pause (SEC)

yes

Quasi stop state

yes
