Spesifikasi Compressor Airman PDS400 :

Portable Compressor (Trailer Type) atau kompresor 400 CFM 7 Bar PDS 400 S – 6B5

Type : Rotary Twin Screw, Single Stage, Oil Cooled

Free Air Delivery : 11.3 m3/min ( 400 CFM )

Working Pressure : 0.70 MPa ( 7.1 kgf/cm2 ) ( 101 psi )

Unloader : Suction Port Closing in Connection With stepless speed regulator

Lublication System : Forced Lubrication by compressed air

Driving System : Direct Coupling with rubber

Oil Cooling : Air cooled

Air Cleaner : Dry Paper filter type

2. OIL SEPARATOR – RECEIVER TANK PDS 400 S – 6B5

Type : Vertical and Cylindrical welded vessel

Shell dia : 350 mm

Shell length ;774 mm

Capacity : 0.0766 m3

Max. Working Pressure 1.0 MPa

Air Outlet Valve : 50A x 1, 20A x 2

3. Engine Mesin PDS 400 S – 6B5 Airman

Model : KUBOTA V3800DI-TIE2B-COHE1

Type : Water cooled, 4 cycle, direct injection, Turbo charged, intercooled

No. of Cylinders : 4

Cyl. bore x stroke : 100mm x 120mm

Total Displacement : 3,769 Liters

Compression Ratio : 19.0 : 1

Rated Output : 72.5 kW / 2600 min1

Injection Pump : BOSCH PFR4M

Governor : Electronic Governor

Alternator : DC 12 V, 960W

Starting Motor : DC 12V , 4.8 kW

Battery : 130F51 x 1

Air Cleaner : Dry Type

Fuel Tank Capacity : 178 Liters

Engine Oil Capacity ( Including oil Cooler ) : 13 Liters

Coolant Capacity ( Including oil cooler ) : 15.6 Liters

Compressors Oil Capacity ( including receiver tank & oil cooler ) : 40 liters

4. Berat PDS 400 S – 6B5

Dry Weight : Standard- 1.740 kg / After Cooler- 1.780 Kg

Operating Weight : Standard- 1.940 / After Cooler- 1.980 Kg
