Working Principle of Infant Resuscitator AD3000-TPA

Neonatal resuscitation also known as newborn resuscitation is an emergency procedure focused on supporting the approximately 10% of newborn children who do not readily begin breathing, putting them at risk of irreversible organ injury and death. Through positive airway pressure, and in severe cases chest compressions, medical personnel can often stimulate neonates to begin breathing on their own, with attendant normalization of heart rate. Infant resusciatator can deliver a more controlled and consistent peak inspiratory pressure (PIP) and positive end-expiratory pressure (PEEP), which helps to protect the newborn's lungs.

Specification of Infant Resuscitator AD3000-TPA

ModelAD3000-TPAPressure gauge-2-10kPa(-20-100cmH2O)

PIP@5 LPM,2-27 cmH2O

@8 LPM,4-36 cmH2O

@10 LPM,6-42 cmH2O

@15 LPM,12-57 cmH2O

CPCP/PEEP@5 LPM,0.3-6 cmH2O

@8 LPM,0.8-14 cmH2O

@10 LPM,1-17 cmH2O

@15 LPM,2.5-23 cmH2O

Noise?50dB(A)Gas source0.3MPa-0.4MPa

Recommended patient weightUp to 10KG
