Easy Installation – Plug the adapter into an available PCI-E slot to upgrade your desktop

High Speed Wi-Fi – Up to 1300Mbps Wi-Fi speeds (867Mbps on the 5GHz band and 400Mpbs on the 2.4GHz band)

802.11ac Dual Band – 3x faster than the 802.11n standard, perfect for busy networks

Beamforming – Receives more directional Wi-Fi signals, improving speed and reliability

Broad Wireless Range – Two external antennas ensure greater Wi-Fi coverage and enhanced stability

HARDWARE FEATURES

Interface PCI Express

Dimensions ( W x D x H ) 4.8 x 4.5 x 0.85 in. (120.8 x 115.2 x 21.5 mm)

Antenna Type 2 Dual Band Detachable Antennas

WIRELESS FEATURES

Wireless Standards IEEE 802.11ac/n/a 5GHz,

IEEE 802.11b/g/n 2.4GHz

Frequency 2.4GHz or 5GHz

Signal Rate 867Mbps at 5GHz,

400Mbps at 2.4GHz

Reception Sensitivity 5GHz :�

11a: -68dBm

11n HT20: -64dBm

11n HT40: -61dBm

11ac HT20: -59dBm

11ac HT40: -54dBm

11ac HT80: -51dBm

2.4GHz :

11b: -76dBm

11g: -68dBm

11n HT20: -64dBm

11n HT40: -61dBm

Transmit Power 5GHz :� <23dBm (EIRP),

2.4GHz :� <20dBm (EIRP)

Wireless Modes Ad-Hoc / Infrastructure mode

Wireless Security Support 64/128 bit WEP, WPA-PSK/WPA2-PSK,802.1x

Modulation Technology DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM

OTHERS

System Requirements Windows 10 (32/64bits), Windows 8.1 (32/64bits), Windows 8 (32/64bits), Windows 7 (32/64bits), Windows XP(32/64bits)

BARANG MASIH MULUS

DIJUAL KARENA LAGI BUTUH UANG
