XP-420B is the new model of Xprinter's 4 inches label printer. Its shell design looks so elegant . Having a space-saving body but keeping a large paper loading container.

One multi-functional button and one two-color indicator, simple operation.

● 6"/s high speed print speed ● 203 dpi resolution models

● 8MB SDRAM，8 MB Flash ● High quality double-walled clamshell design

● Print head temperature intelligent control system make sure printer output stably

The printer use 110mm thermal label paper, and adopt to easy paper loading.

So the paper is very convenient install. And also support printing of various paper specifications.

Basic Features:

1, No paper warehouse design, no ribbon.

3, Dual-wall frame, robust and sturdy structure.

4, TPH special designed overcoat, endure large printing volume.

5, CPCL and TSPL programming language.

Printing :

Resolution - 203dpi

Printing Method -Thermal Transfer/Direct Thermal

Printing Speed - 4-5 Inch/s

Max Printing Width - 104mm (4.09' )

Max Printing Length - 2286mm (90' )

Interface - USB/ (USB+ Serial+Parallel+Ethernet)

Print Head (Abrasive Resistance) - 50km

Commands - TSC

Barcode Type

1D Code - Code39, Code93, Code128 subsets A, B, C, Codabar, Interleaved 2 of 5,

EAN-13,EAN-14, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits

add-on, MSI,PLESSEY, POSTNET, China POS, ITF14

2D Code - QR Code

Picture Format - Graphics Processing - Support BMP/PCX/BAS

Power Supply : Input: AC 110V/240V, Output: DC24V/2.5A,60W

Storage : 4MB

Dimension : 223*286*169mm

Printer Weight : 1.35kg
