MODEL: SPARK MINI

Form Factor (Midi, Micro, Mini ITX, Full): Mini Case

Chassis SPCC: 0.8mm

PSU Form Factor: ATX Support

M/B Form Factor: U-ATX(244*185mm), FLEX-ATX(229*191mm)ITX(170*170mm), m-ATX (19.7 cm x 18.8 cm)

Front Panel: Metal

Top Panel: Top right bottom integrated U-shaped, metal cover,With handle

Side Panel

- Left: Tempered Glass

- Right: Top right bottom integrated U-shaped, metal cover

External Drive Bay(s)

- 5.25" (ODD): *0

- 3.5": *0

Internal Drive Bay(s)

- 3.5" (HDD): *1

- 2.5" (SSD): *2

I/O

- Buttons: *1

- USB3.0 Port(s): *1

- TYPE-C Port(s): *1

Cooling Fan Support

- Front: 0

- Bottom: 2x120MM (Fan optional)

- Rear: 1x80mm,1x90MM (Fan optional)

Slots: *4

Carton & Logo: GAMEMAX

Dimensions Chassis: (L)322*(W)165*(H)263mm

Full Case (inc Fascia): (L)335*(W)165*(H)273mm

Carton: (L)323*(W)225*(H)387mm

VGA Card Length: Up to 300mm(140mm length power)More than 140mm length power supplyGPU Card length support 220MM

CPU Cooler Height: 138mm

SPS Length: 140mm.(More than 140MM length power supply, VGA card length can only support 220MM)
