Fan Specification

Fan Dimensions 120*120*25mm Fan Blade Quantity 7PCS Rated Voltage DC 12V

Material PBT B.RoHS 2.0 Cable Length 400mm Working Voltage DC 6-13.2V

Bearing Type Hydraulic bearing Connector/PWM FAN 4pin ARGB 3pin Start Voltage ≥6V

RPM 800-2000RPM Lighting mode ARGB internal 8PCS Rated Current Fan:0.25A LED 0.35A

Air Flow 62.82CFM Quantity of fans 3PCS Locked Current /

Air Pressure 1.89 mmH2O Noise ≤32dBA Fan Life 40000H

Radiator Specification

Water pump Radiator Water pipe

Dimensions 70*83*53mm Dimensions 397*120*27 Tubing Length 400±10mm

Material PPS Material aluminium Material rubber

RPM 2300RPM±10% Water channel 12PCS Lighting /

Bearing Type Sleeve bearing Noise ≤26.9dBA
