Spesifikasi Produk:

-1698 Channel

-Support GPS, GLONASS, BDS, BEIDOU, GALILEO, SBAS, QZSS, L-band

-Frekuensi 410-470 Mhz

-GNSS Static Horizontal: 2.5 mm + 0.5 ppm RMS Vertical: 3.5 mm + 0.5 ppm RMS

-Static (Long Observation) Horizontal: 2.5 mm + 0.1 ppm RMS Vertical: 3 mm + 0.4 ppm RMS

-RTK(UHF) Horizontal: 8 mm + 1 ppm RMS Vertical: 15 mm + 1 ppm RMS

-RTK(NTRIP) Horizontal: 8 mm + 0.5 ppm RMS Vertical: 15 mm + 0.5 ppm RMS

-Communication Protocol Farlink, Trimtalk, SOUTH

-Communication Range Typically 5-8 km with Farlink protocol,

up to 12-15 km in optimal condition

-NFC Yes

-Storage 16GB SSD internal storage

-Camera Front Camera 8MP, Bottom Camera 2MP

-IMU Tilt Angle 0°~60°

-Dimension 134mm(W) ×134mm(L) × 79.1mm(H)

-Weight 860g (battery included)

-Operating Temperature -45℃~+75℃

-Inbuilt 6800mAh rechargeable Lithium-ion battery

-Battery Life 16h (static) 12h (rover) 10h (built-in UHF base)

-Waterproof / Dustproof IP68 standard, protected from long time immersion to depth of 1m IP68 standard, fully protected against blowing dust

Sudah Termasuk dengan :

-Base & Rover

-Controller

-2x Tripod Statif (Varian Plus Radio Eksternal)

1x Tripod Statif (Varian Tanpa Radio Eksternal)

-1x Stik Pole Jalon

-1x Tribrach for Gps

Bergaransi 1 Tahun
