Image Sensor : 1/3" Progressive Scan CMOS

Shutter Speed : Self-adaptive shutter

Lens : Top Lens: 2.8mm @ F1.6, Field of view : Diagonal 110°, Horizontal 96°, Vertical 54°

Bottom Lens: 6mm @ F1.6, Field of view : Diagonal 60°, Horizontal 52°, Vertical 28°

PT Angle : Pan: 324°, Tilt: 90°

Minimum Illumination : 0.5 Lux @(F1.6, AGC ON),

0 Lux with IR (*data is obtained from EZVIZ laboratories)

Lens Mount : M12

Day & Night : IR-cut filter with auto switch

DNR : 3D DNR

WDR : Digital WDR

Black & White Night : 30 m (98 ft)

Video & Audio

Max Resolution : 2K+ (2880 × 1620)

Frame Rate : Max:15fps; Self-Adaptive during network transmission

Video Compression : H.265 / H.264

H.265 Type : Main Profile

Video Bit Rate ; Ultra-HD; Hi-Def; Standard. Adaptive bit rate.

Audio Bit Rate : Self-Adaptive

Network

Wi-Fi Standard : IEEE802.11b, 802.11g, 802.11n

Frequency Range : 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth Supports : 20MHz

Security : WPA-PSK/WPA2-PSK

Transmission Rate : 11b 11 Mbps, 11g 54 Mbps, 11n: 150 Mbps

Wi-Fi Pairing : AP paring

Protocol : EZVIZ cloud proprietary protocol

Interface Protocol : EZVIZ cloud proprietary protocol

Wired Network : RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Functions

Smart Alarm

AI-powered human shape detection

AI-powered vehicle shape detection

Motion detection

Auto Tracking : Supports

Customized Alert Area : Supports

Two-way Talk : Supports

Preset Locations : Supports

General Function : Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

Storage

Local Storage : Supports microSD card (max. 512 GB)

Cloud Storage : Supports EZVIZ CloudPlay storage (subscription required)

General Operating Conditions : -30°C to 50°C ( -22 °F to 122 °F )

Humidity : 95% or less (non-condensing)

IP Grade : Weatherproof Design

Power Supply : IP65 + 2h rainstorm

Power Consumption : MAX. 18W

Dimensions : 224 × 135 × 136 mm (8.82 × 5.31 × 5.35 inch)

Packaging Dimensions : 255 × 176 × 194 mm (10.04 × 6.93 × 7.64 inch)

Net weight: 723 g (25.51 oz)

With Package: 1203 g (42.43 oz)

In the box

- H90 Dual 2K+ Camera

- Power Adapter

- Drill Template

- Waterproof Kit

- Screw Kit

- Regulatory Information × 2

- Quick Start Guide
