Technical Specification :

Key features

Rega custom full width case with improved heat dissipation

Combined feedback & passive volume control pre-amp

90 watts per channel into 6 Ohms / 72 watts into 8ohms

High specification integrated phono stage

New multi-lingual user manual

Enhanced power supplies for the driver stage

Hybrid of the Brio-R and Elicit-R design

Dedicated mini remote handset included

Pre-amp out / Record out / 4 line inputs

New custom transformer

Specifications

Power Supply

Voltage: 230v & 115v

Frequency: 60/60Hz

Power Consumption: 250 Watts

230v Fuse: T3.15AL 20mm

115v Fuse: T5AL 20mm

Output power

72.5W 8 both channels driven - Design centre rating

90W 6 both channels driven - Rega speaker impedance rating

113W 4 both channels driven

Phono input

Sensitivity (72.5W 81.7mV (Load 47K in parallel with 220pF)

Maximum input level: 100mV

Line input

Sensitivity (72.5W 8 164mv (Load 30-50K)

Maximum input level: 10v

Tape output

Level: 164mV with rated input

Output impedance: 470

Line output

Level: 625mV with rated input

Output impedance: 600

Whathifi Bintang 5, fungsi 100%normal, original blm pernah servis/bongkar.

MINUS TIDAK ADA REMOTE
