Sudah Upgrade Firmware terbaru

Bisa sampling rate tertinggi (24bit/ 1536KHz)

R2R (Super Precision Resistor) untuk sampling audio nya

Suara sangat luwes, tidak kaku (Character Analog)

Detail cek silahkan googling

The Terminator II is a R2R ladder DAC and if you ask around the HiFi community you will hear from those who swear by R2R DACs. I have found that the R2R designs from Denafrips have a way of digging out those details, but with a more musical and natural presentation over their competitors in the R2R field of DAC’s.

One would think using the word “musical” means mushy, slow and soft but none of that applies to the Terminator II. The Terminator II is musical yet detailed at the same time. It has a clarity and detail while projecting a holographic, full and expansive soundstage.

Again, I will say it here..DAC’s can make a big difference in a well tuned, transparent and high end system. For me, the DAVE and now the Terminator II (which I will call the TII from here on) made a bigger improvement to the sound than anything else I have put in (besides speakers of course). Bigger than a pre-amp, amp or cables.

Denafrips DAC’s are made in China and must be ordered from Singapore via Vinshine Audio which is where you can pick up one of these DAC’s. That is not a bad thing really as when we buy direct we pay less and we get more for our money. Period. No middleman and no big ad and marketing campaigns means that truly high end sounds are now within reach for so many more of us into this crazy hobby. That’s pretty cool.

THE TECH SPECS:

Technical Highlights

Proprietary R2R + DSD Architecture

True balanced 26BIT R2R + 6BIT DSD (32 steps FIR Filters)

Matched Precision Thin Film 0.005% R-2R Network Arrays

Encapsulated Flagship Ultra Low Noise Power Supply

Oven Controlled Crystals OCXO

Adaptive FIFO Buffer Reclocking

New Improved Digital Signal Processing FPGA Code

DSD1024, PCM1536 Supports On USB & I²S Input

Proprietary USB Audio Solution via STM32F446 Advanced AMR Based MCU

Licensed Thesycon USB Driver For Windows Platform

Driverless On Mac & Linux

Dual AES/EBU Input Supports

Sharp/Slow Filters Option

I²S Pinout Configuration

I²S DSD Channel Swap Configuration

DSD

DSD64 (DoP) on Coax/AES/Opt Input

DSD1024* On USB & I²S Input Only

PCM

24bits / 44.1, 48, 88.2, 96, 176.4, 192KHz On All Input

1536kHz* On USB & I²S Input

Sampling Mode: Non-Oversampling NOS / Oversampling OS

Digital Input

Coax via RCA

TOSLink x 1

AES/EBU x 2

USB2.0 Type B

I²S via HDMI LVDS

I²S via RJ45 LVDS

I²S via RJ45 LVCMOS

Analog Output

RCA at 2.0Vrms, 625 Ω

XLR at 4.0Vrms, 1250 Ω

Clock Output

44.1KHz, 48KHz

22.5774Mhz, 24.576Mhz

45.1548MHz, 49.152Mhz

Frequency Response: 20-40KHz -0.2dB

THD+N: 0.0015%

S/N Ratio: 127dB

Dynamic Range: >132dB

Stereo Crosstalk: -110dB

AC Power Requirement: 100-240VAC, 50/60Hz (Worldwide Voltage)

Power Consumption: ≤20W

Dimension: 430W x 380D x 125H mm (Includes Footers)

Package Dim: 610 x 570 x 275 mm

Package Content: DAC only. No power cord & remote control.

Weight: 19.0 Kg

Color: Silver / Black
