Switch Type

Unmanaged

Switch Ports

16

Power Consumption

2.36W/8.01W

LEDs

Link, speed, and activity indicators

Dimensions (LxWxH)

288 x 102 x 26 mm

Weight

0.703 kg

Minimum System Requirements

Connected devices need Ethernet connectivity and Ethernet cables

Operating Humidity

10–90% (non-condensing)

Operating Temperature

0–50°C

Ports

16 Gigabit Ethernet (10/100/1000) Ports

Quality Of Service

802.1p and DSCP

Storage Temperature

-40–70°C

Warranty and Support

5 Year Warranty

MAC Address Table Size

8K

Performance

0.01488Mpps for 10M port

0.1488Mpps for 100M port

1.488Mpps for 1000M port

Full line rate and forwarding rate of 64B frame at:

Power

12 VDC, 1 A

Regulatory Compliance

FCC Class B, CE

Fans

None

Power Consumption

2.66 W / 9.32 W

Storage Humidity

10–90% (non-condensing)

Power Saving

Cable connected detection, sleep mode

Network Standards

IEEE 802.3

IEEE 802.3ab

IEEE 802.3az

IEEE 802.3u

IEEE 802.3x

Bandwidth

32 Gbps (non-blocking)
