The Pundit 250 Array brings a quantum leap in the ultrasonic pulse echo testing. A number of unique innovations make the Ultrasonic multi-channel tomography instrument the best and fastest solution for thickness measurements, detecting defects and localizing objects which cannot be easily detected by any other technology. This includes the assessment of thick concrete elements such as tunnel linings as well as pipes and tendon ducts beyond the rebar layer.

The unique real-time B-scan and panorama views allow high resolution imaging directly on-site. Upgrade possibilities to double handle version for increased control and to 16 channels to double the scan width.

Applications

Quality assessment and uniformity

Thickness measurement from a single side

Location of delaminations, voids and honeycoming

Location of hollow pipes

Location of pipes and tendon ducts beyond the rebar layer

Assessment of fibre reinforced concrete

Additional Applications :

Ultrasonic concrete thickness measurement

Honeycomb detection

Features

Instrument Firmware

High resolution imaging of defects, rebars and tendon ducts

Cursors for depth and horizontal displacement information

Settings directly accessible on measuring screen

Raw data export

PC Software

PL-Link for analysis and export of data to third party applications

Display

7” color rugged touchscreen unit (800 x 480 pixels) with dual core processor

Memory

Internal 8 GB flash memory

Connections

USB host / device and Ethernet

Measurement Modes

A-scan

Real-time B-scan

Panorama B-scan

Transducers

Rugged, compact and lightweight Pundit Array Transducer. Standard: Single handed transducer. Dual handle upgrade for increased control (buttons on both handles, optimize gain settings and trigger a measurement). Upgrade to 16 channels for double the scan width

Accessories

Measurement Accessories

Upgrade to 16 channel: Pundit Array Transducer (327 30 100), Pundit Array Transducer Extension Kit (376 30 377) and Dual Handle Kit (327 30 370)

Upgrade to dual handle: Dual Handle Kit (327 30 370)

Pundit Array Transducer Battery Pack Complete (327 30 337)

Rechargeable AA NiMH battery set of 6 (327 30 384S)

Calibrated tape set of 5 (327 01 071S)

Battery complete (327 01 033)

Quick Charger (external) (327 01 053)
