SPECIFICATIONS

“Infinite Possibility”

Version: A1 2.0

Model

Distance Measurement (Reflector)

Range

Accuracy

Measure Time

Distance Measurement (Reflectorless)

Range (Kodak Standard Gray, 90% Diffuse Reflectance)*

Accuracy

Measure Time

Angle Measurement

Detection Method

Diameter of Encoding Disk

Min. Reading

Accuracy

Telescope


Tube Length

Effective Aperture

Magnification

Field of View

Resolution

Min. Focusing Range

Comprehensive parameter

Sensor

Atmospheric Correction

Prsim Constant

Trigger

IP Standard

Vial

Plate Vial

Circular Vial

Plummet

Data Transfer

Display Unit

Type

Size

Graphic Display

Battery

Power Supply

Voltage

Working Hours

Dimention And Weight

Dimention

Weight

Storage

ROM

RAM

Function

GPS

Voice Recording

CPU

Data And Network

Data Transfer

4G

3G/2G

System Version (Sep.2018)

5000m

1000m

Continuous: 0.35s, Tracking: 0.2s, Single: less than 1.2s

1000m

0-300m 3+2 300-600m 5+2 >600m 10+2

Continuous: 0.35s, Tracking: 0.2s, Single: less than 1.2s

Absolute Encoding

79mm

Erect

152mm

Effective: 45mm DTM: 47mm

30X

1°30'

3"

1.5m

Dual-axis Liquid-Electric Sensor (Range: ±3', Accuracy: 1")

T-P Sensor Auto Correction

Auto Correction

Under Battery House

IP55

30"/2mm

8'/2mm

Laser Plummet (Optical Optional)

RS-232C, USB, BLUETOOTH, Flash Disk

LCD, Graphic

5.0 Inch

Lithium Battery

7.4V

8 Hours

206x200x353mm

6.0kgs

32GB

3GB

Available

Available

mt6735

BLUETOOTH*, Wifi*, Wifi Hotspot*

Available

Available

ANDROID 9.0
