Specifications :

Dimensions 325 x 325 x 256 mm

Weight 1.203 kg (2.65 lb)

Power Supply 24V, 0.5A PoE

Max. Power Consumption 6W

Operating Frequency Worldwide USA: U-NII-1 USA: U-NII-2A USA: U-NII-2C USA: U-NII-3

5150 - 5875 MHz 5150 - 5250 MHz* 5250 - 5350 MHz* 5470 - 5725 MHz* 5725 - 5850 MHz*

Gain 22 dBi

Networking Interface (1) 10/100 Ethernet Port

Processor Specs Atheros MIPS 74Kc, 560 MHz

Memory 64 MB DDR2, 8 MB Flash

LEDs (1) Power, (1) LAN, (4) WLAN

Signal Strength LEDs Software-Adjustable to Correspond to Custom RSSI Levels

Max. VSWR 1.5:1

Channel Sizes 5/8/10/20/30/40 MHz

Polarization Dual Linear

Enclosure Outdoor UV Stabilized Plastic

Mounting Pole-Mount (Kit Included)

Wind Loading 145.2 N @ 120 km/h (33 lbf @ 75 mph)

Wind Survivability 120 km/h (75 mph)

ESD/EMP Protection Air: 24 kV, Contact: 24 kV

Operating Temperature -40 to 70 C (-40 to 158 F)

Operating Humidity 5 to 95% Noncondensing

Wireless Approvals FCC, IC, CE

RoHS Compliance Yes

Salt Fog Test IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5

Vibration Test IEC 68-2-6

Temperature Shock Test IEC 68-2-14

UV Test IEC 68-2-5 at 40 C (104 F), Equivalent: ETS 300 019-1-4

Wind-Driven Rain Test ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
