SPECIFICATION

Graphics Engine AXRX 580 4GBD5-3DHDV2/OC

Video Memory 4GB GDDR5

Stream Processor 2304 Units

Engine Clock(OC) up to 1350MHz with boost

Engine Clock(STD/Silent)

Memory Clock 1750MHz x4 (7.0Gbps)

Memory Interface 256-bit

DirectX Support 12

Bus Standard PCIE 3.0

Standard Display Connectors DL DVI-D/ HDMI/ DisplayPort x3

Customized Specifications

Product Remark

Feature Support

OpenGL Support

CrossFireX Technology Support

AMD Stream Technology Support

AMD Eyefinity Technology Support

AMD Hypermemory

Maximum Resolution

VGA

DVI 2560x1600

DisplayPort 4096x2160

HDMI 4096x2160

Power Specs + Board Dimensions

Board Dimensions 255mm*143mm*38mm

Minimum System Power requirement (W) 500W

Power 1x 8-Pin PCI Express

Tersedia 5 unit
