Mixing channel

16 Mono + 3 Stereo + 2 Effect Return + 8 Direct-in to Matrix

Input channel functions, mono CH

3-band PEQ, Comp, Gate, Auto Gain Control, Feedback suppressor (available in ch 1-8)

Output channel functions

Room Delay, Room EQ, Speaker Processor, X-Over (1way,2way), Delay, 6-band PEQ, Limiter

Internal processing

priority ducking, ambient noise compensator

Internal sampling frequency rate

48kHz/ 44.1kHz

Signal delay

less than 3.0 ms (AD-DA @48kHz)

THD

<0.1%

Frequency response

20Hz to 20kHz (+0.5dB, -1.5dB)

EIN

-60dBu (gain +66dB), -83dBu (gain -6dB)

Crosstalk

-100dB

Heat dissipation

55.9kcal/h max

Memory bank

PRESET 50

Power requirements

AC100V-240V 50Hz/60Hz

Power consumption

65W

Dimensions (WxHxD)

18.9" x 3.4" x 13.9"

Weight

13.9 pounds (6.3 kg)
