Spesifikasi Utama

ZOTAC GAMING GeForce RTX 5060 Twin Edge OC

ZT-B50600H-10M

The ZOTAC GAMING GeForce RTX 5060 Twin Edge OC is a compact graphics card powered by NVIDIA‘s cutting edge Blackwell Architecture, DLSS4 and 8GB of GDDR7 memory. With a strong factory OC and solid cooling solution, the Twin Edge OC is ready to take on the latest title releases with smooth framerates and performance.

Feature Highlights:

- Powered by the NVIDIA Blackwell architecture and DLSS 4

- 8-Pin PCIe power connector

- SFF-Ready compact Graphics Card

- Metal Backplate

- BladeLink Fans

GPUNVIDIA GeForce RTX 5060 GPU

CUDA cores3840

Video Memory8GB GDDR7

Memory Bus128-bit

Engine Clock2527 MHz

Memory Clock28 Gbps

PCI ExpressPCI Express 5.0 x8

Display Outputs3 x DisplayPort 2.1b with UHBR20

(up to 4K 480Hz or 8K 165Hz with DSC)

1 x HDMI Connector

(Supports 4K 480Hz HDR or 8K 120Hz HDR with DSC, and Gaming VRR as specified in the HDMI 2.1b Specification)

HDCP Support2.3

Multi Display CapabilityQuad Display

Recommended Power Supply550W

Power Consumption145W

Power Input1 x 8-pin power input

DirectXMicrosoft DirectX 12 Ultimate

OpenGL4.6

CoolingAir Cooled

Slot Size2

SLINo

Supported OSWindows 11 / Windows 10 64-bit (v1809 November 2018 or later)

Card Length220.5mm x 120.25mm x 41.6mm / 8.7" x 4.7" x 1.6"

AccessoriesUser Manual
